12th Firewall Router Intel Core 3 N355 N305 N150 N100 4xi226-V 2.5G DDR5 2*USB3.2 2*NVMe 2*SATA Fanless Mini PC Proxmox Server
£166.67 – £493.81
- Hign-concerned Chemical: None
- Processor Main Frequency: Depends on CPU
- Use: Commercial
- Memory Capacity: ≥ 4GB
- Hard Drive Capacity: 1TB
- Model Number: X4A-L
- Processor Brand: Intel
- Processor Model: N100/N150/N305/N355
- Type: Mini Desktop
- Graphics Card Type: Integrated Card
- Brand Name: kingnovyPC
- Origin: Mainland China
- Certification: CE,FCC,RoHS
- Type: Mini PC
- Feature: Fanless System 0.00dB
- Case Material: Brushed Aluminum Alloy
- Color: Black/Grey by random
- Netwok Ethernet: 4*Intel i226-V 2.5G LANs
|
Processors |
Cores & Threads |
Cache |
Max Turbo Frequency |
TDP |
Graphics |
|
Intel N100 |
4 cores, 4 threads |
6M |
3.40 GHz |
6W |
Intel UHD Graphics 24EUS |
|
Intel Core i3-N305 |
8 cores, 8 threads |
6M |
3.80 GHz |
15W |
Intel UHD Graphics 32EUS |
|
Intel N150 |
4 cores, 4 threads |
6M |
3.60 GHz |
6W |
Intel UHD Graphics 24EUS |
|
Intel Core 3-N355 |
8 cores, 8 threads |
6M |
3.90 GHz |
15W |
Intel UHD Graphics 32EUS |
Product Highlight
-4xIntel i226-V 2.5G RJ45 LANs, 2xUSB3.2, 4xUSB2.0.
-1xDDR5 SODIMM ram slot, support 4800MHz.
-Support triple storage: 2xM.2 2280 NVMe/PCIe3.0x1 2280 SSD+1×2.5 inch SATA3.0 SSD/HDD.
-1xTF card slot support storage and partial system boot.
-Support 4x4K display: 2xHDMI2.1, 1xDP1.4, 1xType-C(support 3-screens display at same time).
-Support wide voltage 12-19V input.
-Support TPM2.0, AES-NI, ESXI, PVE, Watchdog, Auto power on, RTC, PXE boot, Wake-on-LAN etc.
-Full Aluminum Alloy high quality solid-built shell with three-sided long tooth-fins, wide heat dissipation area for excellent cooling performance, exquisite production craft on outside design.
-Fanless system without cooling fan, noiselessness and durability fit for industrial grade field, work as long as 7×24 hours.
-Low consumption TDP and can be mounted back of monitor by VESA bracket(optional).
Package List
1xMini PC
1xPower Adapter
1xPower Cord
1xSATA power&data cable
Internal 8010 cooling FAN cost US $9. If you need them, please pay at this link.
https://www.aliexpress.com/item/3256803167927258.html.
You must be logged in to post a review.
Q1. Can you provide OEM/ODM service? How much do I need to pay for your OEM service?
Re: Yes we can. The charges for OEM service depends on the different level of customize. the process of customization is following:
1) Customer provide specific requirement.
2) Factory draw the design draft.
3) Customer confirm the design draft.
4) Factory start mass prodution.
Q2. Can you print my logo on the mini computer ?
Re: Yes, it is support . And we can make print your logo on the PC for free by laser engraving!
Q3. What is the Minimum Order Quantity (MOQ)?
Re: We can support 1unit sample for your test.
Q4. What is the lead time of your products?
Re: Sample order: 3-7 working days . Bulk order:3~15 working days ( depends on order qty);
Q5. How will you deliver my goods to me?
Re: We can ship by DHL, UPS, FedEx, TNT, etc international air express services;
Q6. What's the warranty?
Re: 3 years long warranty ! Whole lifetime technical support, Buy with confidence!
